Tornillería de SS acuerdo a la solicitud del cliente, puede suministrarse en acero inoxidable SS316.
Estándar:
- Varillas(Espárragos) roscadas de acero de carbono según norma ASTM A307 grado B, .recubrimiento de zinc de 30 micras.
- Tuercas de acero al carbono ASTM A563 grado 5’con un recubrimiento mínimo de zinc de 30 micras.
AUTOPORTANTE Pernos de SS 316
En milímetros
| DN | PN | N° Huecos | Ø x Longitud Esparrago | N° Tuercas | N °Arandelas |
| 50 | 10 | 4 | 5/8″ x 11″ | 20 | 20 |
| 90 | 10 | 8 | 5/8″ x 12″ | 40 | 40 |
| 100 | 16 | 8 | 5/8″ x 12″ | 40 | 40 |
| 150 | 10 | 8 | 3/4″ x 14″ | 40 | 40 |
| 150 | 16 | 8 | 3/4″ x 14″ | 40 | 40 |
| 150 | 25 | 8 | 1″ x 14″ | 40 | 40 |
| 200 | 10 | 8 | 3/4″ x 15 | 40 | 40 |
| 200 | 16 | 12 | 3/4″ x 15 | 40 | 40 |
| 200 | 25 | 12 | 1″ x 15″ | 60 | 60 |
| 250 | 10 | 12 | 3/4″ x 17 | 60 | 60 |
| 250 | 16 | 12 | 1″ x 17″ | 60 | 60 |
| 250 | 25 | 12 | 1″ x 17″ | 60 | 60 |
| 300 | 10 | 12 | 3/4″ x 17 | 60 | 60 |
| 300 | 16 | 12 | 1″ x 17″ | 60 | 60 |
| 300 | 25 | 12 | 1″ x 17″ | 60 | 60 |
| 350 | 10 | 16 | 3/4″ x 17 | 80 | 80 |
| 350 | 16 | 16 | 1″ x 17″ | 80 | 80 |
| 350 | 25 | 16 | 1 1/8″ x 17″ | 80 | 80 |
| 400 | 10 | 16 | 1″ x 17″ | 80 | 80 |
| 400 | 16 | 16 | 1″ x 17″ | 80 | 80 |
| 400 | 25 | 16 | 1 1/4″ x 19″ | 80 | 80 |
| 450 | 10 | 20 | 1″ x 17″ | 100 | 100 |
| 450 | 16 | 20 | 1″ x 17″ | 100 | 100 |
| 450 | 25 | 20 | 1 1/4″ x 19″ | 100 | 100 |
| 500 | 10 | 20 | 1 1/8” x 17” | 100 | 100 |
| 500 | 16 | 20 | 1″ x 17″ | 100 | 100 |
| 500 | 20 | 20 | 1 1/4″ x 20″ | 100 | 100 |
| 600 | 10 | 20 | 1″ x 17″ | 100 | 100 |
| 600 | 16 | 20 | 1 1/4″ x 17″ | 100 | 100 |
| 600 | 25 | 20 | 1 3/8″ x 21″ | 100 | 100 |
| 700 | 10 | 24 | 1″ x 17″ | 120 | 120 |
| 700 | 16 | 24 | 1 1/4″ x 19″ | 120 | 120 |
| 700 | 25 | 24 | 1 1/2″ x 21″ | 120 | 120 |
| 800 | 10 | 24 | 1 1/8” x 18” | 120 | 120 |
| 800 | 16 | 24 | 1 3/8″ x 21″ | 120 | 120 |
| 800 | 25 | 24 | 1 3/4″ x 22″ | 120 | 120 |
| 900 | 10 | 28 | 1 1/8” x 20” | 140 | 140 |
| 900 | 16 | 28 | 1 3/8″ x 20″ | 140 | 140 |
| 900 | 25 | 28 | 1 3/4″ x 26″ | 140 | 140 |
| 1000 | 10 | 28 | 1 1/4″ x 19″ | 140 | 140 |
| 1000 | 16 | 28 | 1 1/2″ x 22″ | 140 | 140 |
| 1000 | 25 | 28 | 2″ x 26″ | 140 | 140 |
